PFAS TESTING

Home / PFAS Testing

THERE ARE MANY TEST METHODS AVAILABLE FOR ANALYZING PFAS. WHICH ONE IS “BEST” DEPENDS ON YOUR PROJECT PARAMETERS AND GOALS.

AOF/EPA 1621

MATRICES: AQUEOUS

Compounds: Absorbable Organic Fluorine (AOF)

AOF/EPA 1621 measures adsorbable organic fluorine in non-potable water. Similar to other organofluorine-based methods, EPA 1621 utilizes CIC instrumentation. The EPA intends EPA 1621 to be utilized as a screening tool to assess organic fluorine concentrations in non-potable water, which often contains many PFAS compounds not detectable by targeted methods such as EPA 1633. The EPA Office of Water describes EPA 1621 as a “Screening Method for the Determination of Adsorbable Organic Fluorine (AOF) in Aqueous Matrices by Combustion Ion Chromatography (CIC).” Its reporting limit is in the single-digit parts-per-billion range. Pace® was chosen to perform the single-lab validation for EPA 1621.

ASTM D8421/EPA 8327

MATRICES: GROUND & SURFACE WATERS, WASTEWATER, LEACHATE, BIOSOLIDS, SOIL & SEDIMENT

Compounds: Up to 44

ASTM D8421 is a PFAS method developed by the American Society for Testing and Materials (ASTM) to provide the industry with a quick, easy, and robust method for PFAS analyses in aqueous matrices. ASTM D8421 utilizes Liquid Chromatography/Tandem Mass Spectrometry (LC/MS/MS), with optional uses of Isotope Dilution (ID) to minimize the impacts of sample matrix interference on quantification and thus improve data quality. Pace® has also successfully used this method for PFAS soil analysis.

Technically similar to EPA 8327, Pace® can cite either method. However, ASTM D8421/EPA 8327 has several advantages over other methods. Turnaround time (TAT) is faster than other published methods that are more procedurally challenging. With optimized procedural requirements, ASTM D8421/EPA 8327 can also be delivered at a much lower price point than other PFAS methods. Finally, ASTM D8421/EPA 8327 only requires a 5 mL of water volume to be collected. This will save significant field collection time and shipping costs compared to other methods, such as Draft Method 1633, which require higher sample volumes.

Consumer and Industrial Products

MATRICES: FLUOROPOLYMERS, TEXTILES, FOOD CONTACT MATERIALS, AND MANY OTHER CONSUMER AND INDUSTRIAL PRODUCTS

Compounds: Up to 33

PFAS is often an ingredient in fluoropolymers and other materials used for packaging and in many commercial and industrial applications. It is also a concern in the container industry and chemical formulation. Pace® has developed a procedure capable of analyzing for 33 common PFAS compounds in consumer and industrial products to support our clients’ efforts to monitor production and manufacturing operations to control the spread of PFAS and comply with the rapidly evolving domestic and International PFAS bans.

DOD QSM 5.4 (TABLE B-15)

MATRICES: GROUND & SURFACE WATERS, WASTEWATER, LEACHATE, WASTEWATER SLUDGE & BIOSOLIDS, SOIL & OTHER SOLIDS, BIOTA, AFFF

Compounds: Up to 25

The DOD QSM (Quality Systems Manual) is not a test method per se. Instead, it is a set of quality control requirements to be used for DOD projects and other state requirements that require DOD QSM compliance.

QSM v5.3 Table B-15 lists the specific requirements for analyzing PFAS in matrices other than drinking water. QSM v5.4 was published in late 2021, adding Table B-24 to include quality control requirements for EPA Draft Method 1633 for DOD projects. Both QSM v5.3 and v5.4 are currently valid, but it’s anticipated that these versions will be superseded by QSM v6.0 when it is finalized.

EPA 1633

MATRICES: WASTEWATER, SURFACE WATER, GROUNDWATER, SOILS, BIOSOLIDS, BIOLOGICAL TISSUES, LANDFILL LEACHATE, AND SEDIMENT

Compounds: Up to 40

Method 1633 closely resembles PFAS by Isotope Dilution/”537M” SOPs and can quantitate 40 compounds across a wide range of solid and aqueous matrices.  EPA 1633 will replace all laboratory-specific SOPs over time. EPA 1633 will also play a vital role in the EPA’s efforts to study, monitor, and regulate PFAS in nearly all matrices and regulatory programs except drinking water. Pace® participated in the multi-lab validation of this method. This method will be adopted into SW-846 for the RCRA program and will soon be promulgated in 40 CFR Part 136.

EPA 537.1

MATRIX: DRINKING WATER

Compounds: Up to 18

An EPA validated method, EPA 537.1 was developed to replace EPA 537 and is commonly used for drinking water compliance. In addition to analyzing for the 14 compounds covered by the original EPA 537, EPA 537.1 also analyzes for four replacement PFAS: 1Cl-PF3OUdS, 9Cl-PF3ONS, ADONA, and HFPO-DA (also known as Gen X).

EPA 533

MATRIX: DRINKING WATER

Compounds: Up to 25

EPA 533 expanded the number of PFAS compounds that can be analyzed in drinking water samples. Unlike the 537 series, this method utilizes isotope dilution, providing additional quality control for accuracy of reporting, especially at ppt (parts per trillion) levels. EPA 533 does not replace EPA 537.1, but together, the tests can be used to analyze for 29 PFAS compounds. EPA 533 is also commonly used for drinking water compliance, and both EPA 533 and EPA 537.1 are required for UCMR 5 compliance.

PACE® IS AN APPROVED UCMR 5 TESTING LABORATORY. YOU CAN LEARN MORE ABOUT THE PROGRAM AND OUR SERVICES ON OUR UCMR 5 PROGRAM PAGE.

PFAS by Isotope Dilution

MATRICES: GROUND & SURFACE WATERS, WASTEWATER, LANDFILL LEACHATE, WASTEWATER SLUDGE & BIOSOLIDS, SOIL & OTHER SOLIDS, BIOTA, AFFF

Compounds: Up to 40

Like many commercial labs, Pace® developed and validated an isotope dilution method based on EPA 537 to apply for non-drinking water matrices such as non-potable water, solids, biota, and biosolids. Able to quantitate 40 PFAS compounds, this method is widely applicable to both DOD and commercial/industrial applications. Furthermore, Pace® has been audited and certified to the accreditation standards of DOD, TNI NELAC, and state accreditation bodies for this method.

TOP Assay

MATRICES: AQUEOUS AND SOLIDS

Compounds: Up To 40, Including PFAS Precursors

PFAS precursors, both known and unknown, are a class of PFAS compounds that can degrade to terminal PFAS compounds (i.e., perfluoroalkyl substances) under the right environmental circumstances. TOP Assay oxidizes PFAS precursors, most of which are compounds not currently measured by targeted techniques, converting them into their terminal PFAS compounds that can then be measured. The increase in PFAS measured after the TOP Assay oxidation relative to pre-oxidation levels is a gross estimate of the total concentration of PFAS precursors present in a sample. PFAS analysis by TOP Assay is particularly useful in forensic studies designed to identify the source of elevated PFAS levels in all matrices. TOP Assay is commonly used on complex sample matrices such as landfill leachate, wastewater, biosolids, and AFFF.

Total Fluorine

MATRICES: SOLIDS

Compounds: Total Fluorine

Two tests are commonly used for analyzing total fluorine in a wide range of solids, such as cosmetics, personal care products, textiles, etc. Cryomilling combined with CIC provides a complete profile of organic and inorganic fluorine content in a sample. Pace® has also partnered with the University of Notre Dame, to offer PIGE (Particle-Induced Gamma-Ray Emission).

Total Organic Fluorine (TOF)

MATRICES: AQUEOUS

Compounds: Total Organic Fluorine

Total organic fluorine in a liquid sample can also be measured without extraction to a carbon media, eliminating extraction efficiency concerns. The technology used for this method is combustion-ion chromatography (CIC) using a novel system where both the inorganic fluoride and total fluorine can be quantitated. A low volume test, this method only requires 10 mL of liquid matrix.
